- Digital length counter meter is used
- Machine operation is easy
- Winding is done, layer by layer, uniformly
- Traverse system is self adjustable
- Coil finishing is excellent
- For the purpose of making coil, many models are there
- For pay off bobbin, mechanical break system is used
| MODEL | MT CL / 1232 |
| ROPE SIZE | 12 TO 32 MM |
| COIL WEIGHT | 110 Kg (Max.) |
| HEAD SPEED | 150 RPM (Max.) |
| MOTOR | 3.7 Kw |
| DIMENSION | 10'5" x 4'8" x 4' |
| WEIGHT | 750 Kg |
Key Features
Optional Features
- Coil to recoil mechanism is used
- AC frequency drive is used
- To remove final package electric wire hoist used
